MMANT-1301000-SM1-000
Antenna
Antenna
2.4 GHz, Wifi Stubby Antenna, Straight SMA Male Connector, Indoor Used
Product Overview
Antenna Protocols
Wi-Fi/BT
Antenna Technology
Wi-Fi
Combination
/
Connector Type
SMA
Gain
Peak Gain(Max):2.4~2.5GHz 3.4dBi
5~6GHz 6.0dBi
6~7.125GHz 4.5dBi
IP-Rating (waterproof?)
IP-66
Impedance
50Ω
Mounting
Screw Mount
Operating Frequency Range
2.4~2.5GHz 5~6GHz 6~7.125GHz
Sub Types
Stubby
Types
External
VSWR
2.4~2.5GHz ≤4
5~6GHz ≤3
6~7.125GHz ≤5
